The Baby Lock Enspire EX is an enhanced version of the original Eclipse DX. The Enspire was released early 2014, featuring Jet Air Threading which threads both Upper and Lower Loopers with a burst of air. The tubular loopers which are used in the Jet Air Threading system allows the machine to be threaded in any sequence, to change any one thread without re-threading other loopers or needles and eliminates tangled threads when stitching is commenced. The Enspire also features built in needle threader, full range differential feed, micro-matic twin cam tension system, 2 LED lights and a shorter distance between the cutting blade and the foot which allows easier stitching of curves.
| Specifications | |
|---|---|
| Machine Type | 4-Thread Overlocker |
| Threading System | JetAir™ |
| Key Technology | |
| Number of Threads | 4 |
| RevolutionAir™ Threading – Needles & Loopers | |
| ExtraordinAir™ Threading | |
| NEW JetAir™ (easier looper threader engagement) | |
| JetAir™ Threading | |
| Tension System | Micromatic Twin Cam |
| Lighting | 2 LED |
| Throat Space | - |
| True 2 to 1 ratio differential feed - ranging from 0.6 to 2 | |
| Knee Lift (Presser Foot) | |
| Variable Speed Control (easily set the maximum speed) | |
| Exclusive Fabric Support System | |
| Vertical Needle System – minimises needle deflection | |
| Advanced Features | |
| Combination Stitch Options | - |
| Coverstitch: triple, wide (6mm), narrow (3mm) & single chain stitch | - |
| Overlocking stitch Options: 4/3/2 Thread | |
| Exclusive Wave Stitch and Reverse Wave Stitch | |
| Automatic rolled hem stitch with the turn of a dial | |
| Flatlock stitch option for seaming and decorative effects | |
| Stitch Length | 0.75 to 4mm |
| Stitch Width – Overlocking | 1.5 to 7.5mm |
| Stitch Width – Expressive (overlocking & coverstitch combined) | - |
| Heavy duty cutting system – cut thick fabrics easily | |
| Presser Foot Pressure Adjustment | Adjustable Screw |
| Presser Foot Height | 6mm |
| Sewing speed (stitches per minute) | up to 1500 |
| Convenience Features | |
| Thread Stand Tray with Magnet | |
| Colour Coded Quick Reference Threading Guide | |
| Built-in Manual Needle Threader | |
| Position of presser foot lever | Rear |
| Included Foot | Grooved Foot |
| Built in Thread Cutter | |
| Guard plate for needle screws | |
| Built in Accessory Storage | |
| Saftey Switches | |
| Needle Drop Tray | |
| Electronic Foot Control | |
| Other Features | |
| Needle Type | HAx1SP |
| Machine Weight | 7.5KG |
| Made in Japan & 5 Year Conditional Warranty | |
| Optional Accessories | |
| Optional Feet Available | 11 |
| Optional Attachments | - |
| Compatibility with Knit Binders/Lap Seam Binder | - |
| Clear Extension Table Compatibility | CT-1 |
